PMSM HVLS Fan
Get a quote

PMSM HVLS Fan

PMSM motor with IP65 grade and under 60℃ temperature characteric

PMSM HVLS Fan

PMSM motor with IP65 grade and under 60℃ temperature characteric

PMSM Ceiling HVLS Fans Model Technology Parameter

Model Fan diameter (m)ft Motor power (kw) Rotate speed (rpm) Full load current Air volume(CMM) m3/min Weight (kg) Max coverage (m2) Noise(dBA)
BGX-ZF-7E 7.3(24') 1.5 0-54 2.3A 15500 138 1800 ≦40
BGX-ZF-6E 6.4(21') 1.5 0-54 1.55A 14500 130 1480 ≦40
BGX-ZF-5E 5.5(18') 1.5 0-65 1.35A 13000 121 1050 ≦40
BGX-ZF-4E 4.6(15') 1.5 0-65 1.2A 12000 112 850 ≦40


01

High performance index, large power factor, high efficiency, and maintain high efficiency in the entire operating speed range; the whole machine has a good energy-saving effect.

02

High power density and small size. The structure is simple, there is no gear box, no oil leakage, and maintenance-free.

03

Long lifetime and high reliability;

04

Good speed regulation performance and high precision; stable operation.

05

The moment of inertia is small, the starting torque is large, the current is small, so that the response speed is fast.

06

The noise is small, even super quiet. No impact on environmental noise.
